CIMC Cement bulker double axle 50 tons banana shape for sale
| Overall dimensions | 11000*2500*4000mm |
| Total volume (m³) | 40~55m³ |
| Related load | 48~60 T |
| Tank Body | |
| Tank thickness | 4 mm |
| Front & end plate | 5 mm |
| Tank rated pressure | 0.2Mpa |
| Discharging System | |
| Diesel Engine | Wei Chai Brand Model 4102 Diesel |
| Air Compressor | FUDA Brand 12 m³ one unit double cylinders compressor |
| Discharging valve | 4 inch butterfly valve |
| Discharging pipe | 3 or 4 inch rubber hose , 1pcs, 6m/each |
| Trailer Chassis | |
| Main Beam | Welded design,Q345B |
| Axles |
3axles |
| Landing gear | 28T JOST C200 |
| Kin pin | 3.5 inch high tensile bolt-in king pin |
| Suspension | Mechanical suspension with 10 layers leaf spring |
| Tire | 12.00R22.5 , 8pcs |
| Braking system | WABCO emergency valve; six double-structure braking chamber; 45L air tank |
| Electrical system | Voltage: 24V ; Receptacle: 7 wire harness |
|
Trailer Performance |
Vertical discharge distance: ≥ 15,000 mm |
| Horizontal discharge distance:≥20,000mm | |
| Discharge speed: ≥1.2 tons / min | |
| Residual :≤ 0.3% | |
| Tool box & tire carrier | One tool box , 2 pieces tire carrier |
| Light & reflector | Rear light, rear reflector, turn indicative light, side reflector,fog lamp,number plate light |
| Painting | Sandblasted,anti-rust chassis surface, one layer anti-corrosive primer, two layers of top coats; |
| Packaging details | BULK CARGO |
