3700mm 45000 Liters Bitumen Tanker Trailer Asphalt Loading

Product Description:

A lot goes into the insulating properties of the bitumen storage tanks for sale to enable the transport of the product to the desired temperature. it is very important for you to understand what makes an Asphalt Tanker unique for transporting the type of product it does.45000 Liters Bitumen Tanker Trailer are designed to meet specific cargo needs and therefore,.

There are a number of considerations to make when transporting asphalt. There are important checks needed during the loading, transportation and offloading of the product that must be done to ensure a successful process.

This is to make sure that the desired characteristics of the cargo are maintained throughout the transportation right from the production center to the desired destination.

3700mm 45000 Liters Bitumen Tanker Trailer Asphalt Loading for Sale In Burkina Faso

CIMC 3 axle bitumen tank for sale

Specification:

Overall dimension: 11500mm * 2500mm *3700mm

Transport：bitumen

Tank Capacity: 38000 liters

Bottom valve: Aluminum API pneumatic bottom valve

Axles：2/3 axles

Suspension：Heavy duty mechanical suspension

Tire：8/12 units

Discharging Pipe: 4'' rubber pipe, 6m/piece, 2 pieces

King pin：2/3.5 inch

Landing gear：JOST

Brake system: 2 line pneumatic brake system

Electrical system: Chinese standard 24V; 7 ways receptacle; LED lamps

Asphalt Loading Operations:

1.Offloading Asphalt. Asphalt needs offloading immediately after it gets to the destination to minimize the colling.

2.Aspalt on Transit. Planning for truck transit should be made in such a way that the transport rated in tons/hour closely matches the production rate and laywdown frequency of the plant.

3.Avoid aggregate segregation when loading your cargo. Asphalt mixes must be placed on the truck bed in a manner that does not enhance aggregate segregation. Dropping the product mix directly from the silo in one big batch creates one pile of asphalt/bitumen mix in the bitumen tanks bed.

4.Truck bed preparation: this should be done before loading the product. Cleaning and lubrication through the use of “release agents” must be done to keep off foreign particles.

5.Ensure you minimize heat loss. Asphalt cools when in transportation and this can adversely affect its characteristics on arriving at its destination and present challenges. To prevent such things as rain, air temperature, duration of length and wind from causing heat loss, insulated bitumen storage tank beds and tarps that cover the load should be put in place.
