3 Axle Cement Bulker Transporters Trailer

3 Axle Cement Bulker Transporters Trailer Product Description:

Cement bulker transporters are used to transport cement trailers. Those we are producing have load capacities from 20 to 60cbm. The carrier consists of a tank on a semitrailer. Mounted inside the tank are chutes that feed air in to the cement, the chutes consist of the metal troug, a porous partition made of special material, and a metal incline .An air compressor is mounted on the chassis of the trailer usually on the front of the trailer. We use  3 head or 2 Head, powered compressor with pistons and Diesel Deutz motor or Electirical motor Bekomsan brand.

Specification:

Brand: CIMC 3 Axle Cement Bulker Transporters Trailer

Total Volume (m³): 25 cbm ~60 cbm

Tanker Body Material: 5mm or 6mm/ high strength wear-resistance steel

Diesel Engine: WEICHAI 4105 Brand

Compressor: BOHAI, FUDA 12m3/14 m3or other brands

Manhole Cover: Carbon steel or Aluminum 500mm(Diameter)

Discharging Valve: Diameter is 3 or 4 inch

Main Beams: Welded design, High Strength Steel

Axle: 3 axles, 14 ton

Suspension: Mechanical suspension
