Agricultural Three Axle 40 Foot Skeleton Chassis Trailer

Agricultural Three Axle 40 Foot Skeleton Chassis Trailer

Intermodal trailers Description:

CIMC Tri axle chassis for sale 40ft container skeleton trailer is currently used in port. CIMC terminal trailer is a high capacity terminal trailer capable of carrying a container payload of up to 70 tons. This trailer is designed to transport either a single 20ft, twin 20ft, a 40 ft, or a 45ft container at once.

You just have to drop 'em boxes and take 'em boxes. The application of the terminal trailer increased the handling rate by 30%; capable of operating flippers without entangling with other containers.

For the product quality, we used high strength steel at the main beam, this makes the product carry large capacity and the product does not cause product deformation. We not only provide high quality products but also provide quality pre-sale services and after-sales services. So you can rest assured to buy our products.

Specification:

Type: Intermodal trailers

Overall dimensios: 12400x2500x1550 mm

Loading weight: 30ton -50 ton

Container twist lock: 8/12 pcs

Main beam: Q345B steel

Side beam: 16 U shaped steel or I shaped steel

Axle brand: FUWA/BPW/CIMC brand

Traction pin: 2” or 3.5”

Landing gear: Standard 28 ton, brand optional

Suspension system: Mechanical suspension, air suspension is optional

Tire: 12.00R22.5 Triangle brand tires, others tires optional

Brake: 6 big chamber brake system

Tool box: 1 unit

Side marker lamp: LED type

Voltage: 24V

Feature:

1. The optional Jost landing leg, is a world recognized famous brand accessory with Better bearing capacity and long service life.

2. Cargo container trailer braking system, effective braking, fast braking response, braking distance reduced by more than 5m.

3. Polyurethane paint, high adhesion, high chroma, beautiful color.

4. Able to custom-built design as your requirement, ensure to meet your local road regulation.

5. The 40 feet container trailer brake gas pipe of semi-trailer adopts a high-pressure rubber gas pipe, with a service life of more than 10 years.

6. The whole intermodal trailer adopts LED lamps and lanterns, and a set of tail lamps and side lamps will be presented when the goods are delivered.

7. The suspension of the container chassis trailer is made of special high-strength rigid steel, 70mm center balance pin, Other factories use light suspension, the pin is only 45mm, the service life is short, it will cause abnormal wear.
