40cbm Dry Bulk Tank Trailer

40cbm Dry Bulk Tank Trailer Product Description:

The dry bulk tank (aka “pneumatic trailer”) is basically a metal cylinder with a series of cone-shaped hoppers at the bottom and a series of openings (or “manholes”) at the top and back of the tank.  At the bottom of each hopper is a valve, opening into a pipe that runs below the trailer. Those valves are closed when a shipper loads the truck. When it comes time to unload, the driver opens them, letting product run out of the hopper and into the pipe.

Specification:

Brand: CIMC Dry Bulk Tank Trailer

Total Volume (m³): 25 cbm ~60 cbm

Tanker Body Material: 5mm or 6mm/ high strength wear-resistance steel

Diesel Engine: WEICHAI 4105 Brand

Compressor: BOHAI, FUDA 12m3/14 m3or other brands

Manhole Cover: Carbon steel or Aluminum 500mm(Diameter)

Discharging Valve: Diameter is 3 or 4 inch

Main Beams: Welded design, High Strength Steel

Axle: 3 axles, 14 ton

Suspension: Mechanical suspension
