Tri Axle Flat Deck Trailer

Product Description:

CIMC tri axle flat deck trailer is another commonly used type of container and equipment in the transportation industry.

This tri axle flat deck trailer is very popular in the African market because of its multi-function to carry container, bulk cargo, bagged cement and the other kind of goods. This tri axle flat deck trailer can bear a 60 tons payload.

Flat deck trailer manufacturers - CIMC trailer is widely exported to South-east Asia, Middle-east, and Africa market.

Tri Axle Flat Deck Trailer for Sale in Harare - CIMC Trailers

Specification of flat deck trailer:

Overall L*W*H: 12,500×2,500×1,530 mm

Payload: 60 tons

Axles: 13 tons / 14 tons / 15 tons /16tons / 20 tons ( Fuwa/BPW /CIMC or other Chinese famous brand )

Tire: 12.00R20 / 11.00R20 / 12R22.5 / 385/65R22.5, optional

Landing gear: JOST

Kingpin: 50(2inch)#or 90(3.5inch)# bolted type

Suspension: Mechanical / airbag / bogie suspension

Brake system: WABCO brake system with dual brake chambers and emergency brake valve

Container lock: 12 pcs

Valve: WABCO valve (specially intended for oversea market)

ABS: Optional

Light: LED light (specially intended for oversea market)

Voltage: 24V

Socket(Receptacle): 7-pin Socket (for 7 wire harness)

Accessories: Tool box , spare tire carrier

Advantages:

1. We adopt premium steel material, advanced technology and strict production to our flatbed trailer.

2. The tri axle flat deck trailer painted by advanced painting system, the painting effect can meet Swedish Sa2.5 class marine anti-corrosion standards.
3. Good brake effects. Axles are equipped with WABCO emergency brake valve also dual-brake chambers also widen brake pads.

4. All spare parts used by CIMC are world famous brands to ensure the service life of flatbed semi trailers.

The function of a tri axle flat deck trailer is made possible through its structure’s design and manufacture.Basically, it is a transport equipment mainly of a steel construction defining its frame. It also comprises a lighting system, brakes and tires.It is carefully designed to desired heights and weight capacity to safely load and transport cargoes from one location to another.Use tri axle flat deck trailer to transfer cargo at the shipper’s warehouse. Unloaded to the consignee’s warehouse, when changing trailer or boat on the way, there is no need to take the goods out of the box and change them.
