Name: CIMC End Dump Trailer
Capacity: 40T
Lifting system: Hydraulic Lifting Cylinder
Axle: 3 axles, 13T/16T, optional
King Pin: 50#, 90#
CIMC End Dump Trailer for Sale adopts high strength steel T700, offering all the durability of high-tensile-strength steel and unique structure design to maximize payload to increase your profitability. So, CIMC designs one of the strongest Tipper Trailers for Sale on the road today.
CIMC End Dump Trailer for Sale equipped with reliable hydraulic cylinder. We can customize CIMC End Dump Trailer for Sale according to your special need, like U shape dump trailer, end dump semi trailer, side tipper, and container tippers.
CIMC 4 Axle 30CBM End Dump Trailer for Sale in Senegal Dakar
Specification:
Name: CIMC End Dump Trailer
Tare weight: 40T
Bottom plate thickness(mm): 5mm-8mm /Q235 steel or can be optional
Lifting system: Full set of Hyva (FC214-5-07130) Hydraulic Lifting Cylinder
Main Beams: Height:500mm, upper plate is 16mm,middle is 8mm(double+three plate),down plate is 18mm,material is Q345B steel
Axle: 3 axles, 13T/16T, FUWA/BPW/ Brand
Landing Gear: JOST (D200T)or China Brand 28Tons
King Pin: 50#, 90#
Suspension: Mechanical suspension or Air suspension
