The suspensions of 3 Axle 42000L Stainless Steel Tanker Semi Trailer can be Air suspension, mechanic (leaf spring suspension), bogie suspension, etc. The 3 Axle 42000L Stainless Steel Tanker Semi Trailer inside can be isolated compartments or single compartment by your needs.
The tank body is made of high-quality 6mm stainless steel in one roll forming, which is completely seamless. There are multiple anti-wave baffles in the tank body, and the high-pressure gas leak test is adopted to make the tank body have the characteristics of high strength, stable center of gravity, and safe and stable vehicle transportation.
Dimension: 12100mm*2500mm*3900mm(the exact size depends on the final design)
Volume: 42000liters
Application: transport Fuel, Oil, Diesel
Tank body:
Material: stainless steel
Tank body and separate compartment plate: 6mm
Compartments: 1 to 7 compartments, based on customer needs
Manhole cover: Carton steel or Aluminum alloy API manhole cover 500mm (diameter)
Discharge valve: Diameter is 3 or 4 inch
Bottom valve: Aluminum API Pneumatic Bottom Valve
Tanker body test: Hydrostatic test to 5 psi (35 Kpa) on each compartment
Chassis:
Axles: 3 units, FUWA/BPW/CIMC/other
Landing Gear: JOST brand
King Pin: JOST brand 2.0 or 3.5inch(bolted or welded type)
Suspension: Mechanical suspension or air suspension
Brake System: WABCO
Tire: 12.00R22.5/315.80R22.5/11.00R20/12.00R20 brand can be optional
