38000 Lts Aluminum Tanker Trailer

Aluminum Tanker Trailer Price: 24500USD

CIMC 38000 lts aluminum tanker trailer are mainly used for transporting liquid and oil. CIMC 38000 lts aluminum tanker trailer body is generally made of carbon steel sheet, and it can also be made of aluminum alloy, stainless steel, polyethylene and other materials. CIMC 38000 lts aluminum tanker trailer adopt advanced design concept.

CIMC 38000 Lts Aluminum Tanker Trailer for Sale Price In Costa Rica

CIMC 38000 Lts Aluminum Tanker Trailer for Sale Price In Costa Rica

CIMC 38000 Lts Aluminum Tanker Trailer for Sale Price In Costa Rica

CIMC 38000 Lts Aluminum Tanker Trailer for Sale Price In Costa Rica

CIMC 38000 Lts Aluminum Tanker Trailer for Sale Price In Costa Rica

Specification of Aluminum Tanker trailer:

Dimension: 11500mm * 2500mm *3700mm (the exact size depends on the final design.)

Tare Weight (semi trailer): About 8000-12800kg

Total volume: 38000lts

Axle: 3 axles,16T,FUWA

Landing Gear: JOST(D200T) or China brand 28T

Kingpin: JOST 2.0 or 3.5 inch bolt-in king pin

Suspension: Mechanical suspension

Compartments: 5 Compartments

Tank Body Material: 5mm aluminum alloy

End plate: 5mm

Manhole Cover: Aluminum alloy

Bottom Valve: Aluminum  API Pneumatic Bottom Valve

Discharging Valve: Diameter is 3 or 4 inch

Discharging Pipe: 4 inch rubber hose,2pcs,6m/each

Cat Walk: With (common model or special design)

Main beams: Welded design or special design I beam, connected by bolts and nuts Q345 carbon steel material

Leaf Spring: 90(w)mmx13(thickness)x10layers or 10mm x12mmx12 layers

Pneumatic Braking System: WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber(TKL brand); 45L air tank

Rim: 9.00-22.5/8.00-20/8.5-20 Chinese brand

Tire: 12.00R22.5/315.80R22.5/11.00R20/12.00R20 brand can be optional

ABS: Optional

Painting: Sandblasted, anti-rust chassis surface is available with 1 layer of anticorrosive primer and 2 layer of top coats.

Accessories: One standard tool box

Shipping Terms: By bulk cargo, RORO or 40HQ containers
