Table of Contents
Chapter 1.1 How Much is the Price of a Fuel Tanker Trailer for Sale?
Chapter 1.2 Fuel Tanker Trailer Cost Capacity Dimensions Specification
Chapter 1.3 Different of Fuel Tanker Trailer and Aluminum Tanker Trailers
Chapter 2. Advantage of Fuel Tanker Trailer for Sale In Ghana
Chapter 3. How to Connect and Separate Tanker Trailer for Sale and Tractor
Chapter 4. Fuel Trailers for Sale Shipping Method
CIMC fuel tanker trailer for sale used to transport petrol, diesel, gasoline, crude oil etc bulk petroleum products, as well as water, and milk liquid. CIMC can produce Aluminum Alloy, Carbon Steel and Stainless Steel tanker trailers for sale. To build the most durable and strong tankers, especially for Africa Market need to consider the road conditions.
Tanker capacity we supply with 30000 litres, 32000 litres, 35000 litres fuel tanker trailer for sale, 38000 litres fuel tanker trailer cost, 40000 litres fuel tanker trailer, 42000 litres tanker trailers for sale, 45000 litres fuel tanker trailer for sale, 30000-90000 liters tanker trailer can be customized.
Compartments of oil tank semi trailers also have multiple options, have one compartment, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12 compartments for your different transit needs.
China CIMC fuel tankers trailer for sale with good pressure-bearing, anti-distortion, anti-vibration and explosion-proof performance make your fuel tanker trailers much safer and more beneficial.
3 Axle 38000 Liters Fuel Tanker Trailer Price: 15500USD
45000L Fuel Tanker Price: 16000USD
50000 Liters Fuel Tanker Trailer Cost: 16800USD
60000 Ltrs Fuel Tank Trailer Price: 18500USD
70000 Litres Tanker Trailers Price:21500USD
Fuel Tanker Trailer for Sale In Ghana | 38000 Liters/45000 Liters/50000 Litre Tankers Cost
Shape: Round or square
Dimension: 12000mmx2490mm x3990mm (the exact size depends on the final design.)
Tare Weight (semi trailer): About 8000-12800kg
Total volume(L): 30000-90000L
Tank Body Material: 5mm or 6mm/Q235 carbon steel
Main beams: Welded design or special design I beam, connected by bolts and nuts Q345 carbon steel material
Kingpin: JOST 2.0 or 3.5-inch bolt-in kingpin
Suspension: Mechanical suspension /Germany or America type /Air Suspension
Axle: 2 or 3 or 4 axles,12T/13T/16T,BPW/ FUWA/ CIMC brand
Landing Gear: JOST(D200T) or China brand 28T
Rim: 9.00-22.5/8.00-20/8.5-20 Chinese brand
Tire: 12.00R22.5/315.80R22.5/11.00R20/12.00R20 brand can be optional
Manhole Cover: Carton steel or Aluminum alloy API manhole cover 500mm (diameter)
Endplate: 5mm or 6mm/Q235 carbon steel
Discharging Valve: Diameter is 3 or 4 inch
Bottom Valve: Aluminum API Pneumatic Bottom Valve
Compressor: BOHAI 10m³/12m³ or other brands
Compartments: Optional
Discharging Pipe: 4 inch rubber hose,2pcs,6m/each
Cat Walk: With (common model or special design)
ABS: Optional
Painting: Sandblasted, anti-rust chassis surface is available with 1 layer of anticorrosive primer and 2 layers of topcoats.
Accessories: One standard toolbox
Shipping Terms: By bulk cargo, RORO or 40HQ containers
Carbon steel 45000 liters fuel tanker trailer sold generally have a stronger structure to support weight than aluminum trailers. This is an important factor to be aware of when choosing a tanker to sell.The steel option is cheaper than an aluminum semi because of the manufacturing process involved. Steel is easier to manufacture than aluminum, especially in terms of welding possibilities.Unlike aluminum.
Carbon steel tankers are easily corroded when loaded with gasoline and diesel. The inside of the tank is prone to rust, which causes the oil to be contaminated, which in turn leads to early wear and tear of the vehicle engine, which greatly reduces the service life of the engine.
Aluminum fuel tanker trailer is one kind of fuel tanker trailer but the material is aluminum. The main transportation media liquids are gasoline and diesel. For 45000 liters fuel tanker trailer, the tank body is made of 5mm or 6mm high-quality aluminum alloy according to national standards. The shape of the aluminum fuel tanker trailer’s tank body is divided into oval or square round tanks, which can contain 1-4 kinds of oil products. Aluminum fuel tanker trailer can also produce heating and heat preservation series tanks.
An aluminum tanker trailer is generally used in countries with limited weight. If the weight of the tank is reduced, the weight of the load can be increased.The main challenge for aluminum semi-trailers is the cost due to the complexity of welding aluminum.
The use of aluminum tanker trailer can not only greatly reduce the vehicle’s own weight and improve transportation efficiency, but also has a long service life, which is 5-10 years longer than that of steel tanker. During the entire life cycle, the profits created are very considerable.
Fuel Tanker Trailer for Sale In Ghana | 38000 Liters/45000 Liters/50000 Litre Tankers Cost
Fuel tanker trailer for sale in Ghana less oil residual, less business running cost. According to the characteristics of the oil, the precise angle design and Welding ensure that the oil in each bin can have the least residual quantity when unloading, so as to ensure the minimum residual quantity in the bin after every time the oil is transported and unloaded. The professional design ensures fast oil unloading speed and improves work efficiency while also ensuring
Discharge port: it can be set on the left or right side according to customer needs. The discharge port can also be changed to the discharge port of the European system according to customer requirements. Some customers request different compartments for their transit business. CIMC can produce one single compartment, 2 compartments, 3 compartments, 4 compartments, 5 compartments, 6 compartments, 7 compartments, 8 compartments, etc.
Never oil leakage of fuel tanker trailer for sale in Ghana. No oil will be spilled between each bin. This is because tank trucks use double-sided welding instead of single-sided welding for each compartment plate.
The tank body uses the most advanced welding technology, through single-sided welding and double-sided forming welding, which will make the welding seam stronger and smoother. The fuel tanker trailer for sale in Ghana tank body welded by this method will never open the welding phenomenon, and the tank body can usually be used for more than 10 years.
Fuel Tanker Trailer for Sale In Ghana | 38000 Liters/45000 Liters/50000 Litre Tankers Cost
Double-sided welding can not only reduce the probability of welding seams during use but also make the bulkhead have better support for the tank body through double-sided welding.
Similarly, the fuel tanker trailer for sale in Ghana is also painted with polyurethane, which is beautiful in color and twice the cost of ordinary paint. Color will not fade within 5 years of use.
After welding, the whole vehicle is sandblasted several times to remove rust to increase the adhesion of the paint. the paint of the fuel tanker trailer for sale will be sprayed 3 times, one anti-rust paint, and two topcoats.
Each oil tank uses the best domestic subsea valve brand: Use European standard manhole cover: explosion-proof and flame-proof function, and equipped with breathing valve, can maintain the pressure balance inside and outside the tank. The tank cover will not open after the tank body collides and rolls over, and the discharge port at the bottom of the tank is equipped with an emergency shut-off valve subsea valve.CIMC uses a European standard pair of explosion-proof covers. There are breathing valve, oil and gas recovery valve and anti-overflow valve inside.
CIMC has exported fuel tanker trailer for sale in Ghana for more than 20 years. Customers’ feedback has always been that it’s safe and fast to unload oil, and they pull more oil than other oil tanks, which can generate a lot of profits in one year.
CIMC can produce custom-made fuel tanker trailer for sale in Ghana for your options. Different customers have various demands for their oil tanker trailers. CIMC can produce per each customer's special need on the fuel tanker trailer for sale.
Fuel Tanker Trailer for Sale In Ghana | 38000 Liters/45000 Liters/50000 Litre Tankers Cost
How Tanker Trailers for Sale Connects with Tractors
In order to make the connection between the traction pin and the traction seat smooth, the semi-trailer wheels should be plugged with wooden blocks first. It is advisable to raise the outriggers so that the center position of the tanker trailers for sale traction pin seat plate is about 10mm-30mm lower than the traction seat of the tractor. Otherwise, sometimes not only can not be connected but also damage the traction seat, traction pin and related parts.
Pull the release lever of the tow seat on the tow vehicle to open the tow lock mechanism. Reverse the traction pin, open the traction pin through the V-shaped opening of the traction seat, guide the locking mechanism, push the locking block to rotate, and lock the traction pin. When the tractor backs up, the centerline of the tractor and tanker trailers for sale should be aligned.
Connect the gas circuit, and open the gas connection separation switch of the semi-trailer on the tractor.
To connect the circuit, insert the tractor's wiring plug into the tanker trailers for sale wiring socket. Correctly operate the lifting leg to retract, then pull down the swing arm to hang on the hook.
Fuel Tanker Trailer for Sale In Ghana | 38000 Liters/45000 Liters/50000 Litre Tankers Cost
How to Separate Tanker Trailers for Sale
Try to choose a flat and solid ground to separate the tanker trailers for sale from the tractor. In summer, if the foundation is soft or the asphalt pavement is separated, a thick wooden block should be placed under the base of the lifting leg to prevent it from sinking due to its own weight and cannot be reconnected. Pull the truck head handbrake to make the brakes safe.
Close the disconnect switch on the tanker trailers for sale air connector on the tractor, then remove the tractor air connector from the tanker trailers for sale. Unplug the cable connection for tanker trailers for sale.
Operate the lifting legs so that the base of the lifting legs touches the ground, then downshift to lift the tanker trailers for sale some clearance in order to exit the truck head. Pull out the tow base, unlock the lever, and open the lock block.
Pull the tractor forward slowly to separate the tow pin from the tow seat and separate the tanker trailers for sale from the tractor.
Check whether there is any abnormality in each part of the separated tanker trailers for sale, unscrew the drain valve at the bottom of the air tank, and drain the water in the air tank.
There are mainly five transportation schemes for customers to obtain fuel trailer for sale, and there are four main types of shipping: bulk shipping, flatbed shipping, ro-ro shipping and container shipping, one of which is land transportation. There are also some countries that also choose container or flatbed transportation. We will spray wax on the gasoline trailer
Shipping is mainly for overseas customers, mostly African customers, Nigerian customers, Ghana customers, Zimbabwe customers, Democratic Republic of Congo customers, Mozambique customers, Tanzania customers, Senegal customers, Costa Rica customers, Burkina Faso customers, Mali customers, etc.
As a professional semi-trailer supplier, in the era of increasing efficiency, the delivery method we adopt is also an important reason to ensure a better customer experience. We also recommend that customers choose container delivery, and try not to choose Bulk carriers, for the following reasons:
Since the loading and unloading of containers are basically not affected by harsh weather, the non-productive berthing time of ships is shortened, and due to high loading and unloading efficiency, the loading and unloading time is shortened.
Since the container is a solid and sealed box, the container itself is a solid package. After the goods are packed and sealed, there is no need to unpack and reload on the way. Even after long-distance transportation or multiple replacements, it is not easy to damage the goods in the box.
Container transportation can reduce cargo damage and cargo differences caused by theft, moisture, contamination, etc.
In order to prevent the goods from being damaged in transit, it is necessary to have strong packaging, and the container has the characteristics of strong and airtightness, which is excellent packaging in itself, which can greatly save packaging costs.
Fuel Tanker Trailer for Sale In Ghana | 38000 Liters/45000 Liters/50000 Litre Tankers Cost
